Wheel size
Ride-1 Position
| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 575 | 600 | 625 | 655 |
| Head Tube Angle (deg) | 66.5 | 66.5 | 66.5 | 66.5 |
| Head Tube Length (mm) | 115 | 125 | 125 | 135 |
| Seat Tube Angle (deg) | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube Length (mm) | 394 | 432 | 470 | 508 |
| Rear Centre (mm) | 435 | 435 | 435 | 435 |
| Bottom Bracket Drop (mm) | 58 | 58 | 58 | 58 |
| Reach (mm) | 390 | 412 | 437 | 464 |
| Stack (mm) | 626 | 635 | 635 | 644 |
| Standover Height (mm) | 804 | 805 | 800 | 802 |
| Wheelbase (mm) | 1120 | 1146 | 1171 | 1202 |
| Top Tube Horizontal (mm) | 575 | 600 | 625 | 655 |
| Head Tube Angle (deg) | 66.5 | 66.5 | 66.5 | 66.5 |
| Head Tube Length (mm) | 115 | 125 | 125 | 135 |
| Seat Tube Angle (deg) | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube Length (mm) | 394 | 432 | 470 | 508 |
| Rear Centre (mm) | 435 | 435 | 435 | 435 |
| Bottom Bracket Drop (mm) | 58 | 58 | 58 | 58 |
| Reach (mm) | 390 | 412 | 437 | 464 |
| Stack (mm) | 626 | 635 | 635 | 644 |
| Standover Height (mm) | 804 | 805 | 800 | 802 |
| Wheelbase (mm) | 1120 | 1146 | 1171 | 1202 |
These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size. Rocky Mountain always recommends test riding and professional bike fitting at an authorized dealer.
Frame Size
157.5 - 170 cm / 5’2” - 5’7”
167.5 - 177.5 cm / 5’6” - 5’10”
175 - 188 cm / 5’9” - 6’2”
185.5 - 198 cm / 6’1” - 6’6”
