Wheel size
RIDE-9/4 POSITION
| kids | |
|---|---|
| Top Tube Horizontal (mm) | 517 |
| Head Tube Angle (deg) | 67 |
| Head Tube Length (mm) | 100 |
| Seat Tube Angle (deg) | 71 |
| Seat Tube Length (mm) | 310 |
| Rear Centre (mm) | 382 |
| Bottom Bracket Drop (mm) | 33 |
| Reach (mm) | 350 |
| Stack (mm) | 497 |
| Standover Height (mm) | 656 |
| Wheelbase (mm) | 960 |
Standover height is measured 200 mm in front of the bottom bracket.
| Top Tube Horizontal (mm) | 517 |
| Head Tube Angle (deg) | 67 |
| Head Tube Length (mm) | 100 |
| Seat Tube Angle (deg) | 71 |
| Seat Tube Length (mm) | 310 |
| Rear Centre (mm) | 382 |
| Bottom Bracket Drop (mm) | 33 |
| Reach (mm) | 350 |
| Stack (mm) | 497 |
| Standover Height (mm) | 656 |
| Wheelbase (mm) | 960 |
Standover height is measured 200 mm in front of the bottom bracket.
These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size. Rocky Mountain always recommends test riding and professional bike fitting at an authorized dealer.
Frame Size
129.5 - 140 cm / 4’3” - 4’7”
