Element Carbon 50

Element Carbon 50

Element Carbon 50

Rated 4.3 out of 5

Based on 4 reviews

Overview

Intended use: Cross country

Rear travel: 120

Description

Purpose-built to hit the precise sweet spot between lightweight cross country climbing prowess and technical precision, the Element is the best of both worlds and more. New-levels of climbing efficiency guarantees that oh-so-sweet feeling of riding someone off your wheel. Added levels of stability on fast descents and a pseudo-aggressive seat tube angle provides surprising levels of confidence on tight single track and hairy descents. Light. Stiff. Fast. Smooth. Precise. You’re now in your Element—always.

Wheel Size:

29

29 27.5

Color:

UD Carbon / Black Dog /

Variant

Register your Element Carbon 50

Specifications

Geometry

Wheel size

RIDE-9/4 POSITION

Learn more

RIDE-9/4 POSITION

Learn more

View from drive side

	sm	md	lg	xl
Top Tube Horizontal (mm)	577	605	632	664
Head Tube Angle (deg)	65	65	65	65
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76	76	76	76
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	436	436	436	436
Bottom Bracket Drop (mm)	47	47	47	47
Reach (mm)	425	450	475	505
Stack (mm)	606	615	624	633
Standover Height (mm)	810	808	806	804
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	sm	md	lg	xl
Top Tube Horizontal (mm)	577	604	631	663
Head Tube Angle (deg)	65.2	65.2	65.2	65.2
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.2	76.2	76.2	76.2
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	43	43	43	43
Reach (mm)	427	452	477	507
Stack (mm)	607	616	625	635
Standover Height (mm)	811	809	807	805
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	sm	md	lg	xl
Top Tube Horizontal (mm)	576	603	631	663
Head Tube Angle (deg)	65.5	65.5	65.5	65.5
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.5	76.5	76.5	76.5
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	40	40	40	40
Reach (mm)	430	455	480	510
Stack (mm)	609	618	627	636
Standover Height (mm)	812	810	809	807
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	sm	md	lg	xl
Top Tube Horizontal (mm)	575	603	630	662
Head Tube Angle (deg)	65.8	65.8	65.8	65.8
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.8	76.8	76.8	76.8
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	36	36	36	36
Reach (mm)	433	458	483	513
Stack (mm)	610	619	628	637
Standover Height (mm)	813	811	810	808
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	577	605	632	664
Head Tube Angle (deg)	65	65	65	65
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76	76	76	76
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	436	436	436	436
Bottom Bracket Drop (mm)	47	47	47	47
Reach (mm)	425	450	475	505
Stack (mm)	606	615	624	633
Standover Height (mm)	810	808	806	804
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	577	604	631	663
Head Tube Angle (deg)	65.2	65.2	65.2	65.2
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.2	76.2	76.2	76.2
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	43	43	43	43
Reach (mm)	427	452	477	507
Stack (mm)	607	616	625	635
Standover Height (mm)	811	809	807	805
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	576	603	631	663
Head Tube Angle (deg)	65.5	65.5	65.5	65.5
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.5	76.5	76.5	76.5
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	40	40	40	40
Reach (mm)	430	455	480	510
Stack (mm)	609	618	627	636
Standover Height (mm)	812	810	809	807
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	575	603	630	662
Head Tube Angle (deg)	65.8	65.8	65.8	65.8
Head Tube Length (mm)	105	115	125	135
Seat Tube Angle (deg)	76.8	76.8	76.8	76.8
Seat Tube Length (mm)	380	420	445	480
Rear Centre (mm)	435	435	435	435
Bottom Bracket Drop (mm)	36	36	36	36
Reach (mm)	433	458	483	513
Stack (mm)	610	619	628	637
Standover Height (mm)	813	811	810	808
Wheelbase (mm)	1173	1202	1231	1265

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	xs
Top Tube Horizontal (mm)	542
Head Tube Angle (deg)	64.7
Head Tube Length (mm)	90
Seat Tube Angle (deg)	75.7
Seat Tube Length (mm)	355
Rear Centre (mm)	426
Bottom Bracket Drop (mm)	28
Reach (mm)	397
Stack (mm)	561
Standover Height (mm)	769
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	xs
Top Tube Horizontal (mm)	542
Head Tube Angle (deg)	64.9
Head Tube Length (mm)	90
Seat Tube Angle (deg)	75.9
Seat Tube Length (mm)	355
Rear Centre (mm)	426
Bottom Bracket Drop (mm)	26
Reach (mm)	400
Stack (mm)	563
Standover Height (mm)	770
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	xs
Top Tube Horizontal (mm)	541
Head Tube Angle (deg)	65.3
Head Tube Length (mm)	90
Seat Tube Angle (deg)	76.1
Seat Tube Length (mm)	355
Rear Centre (mm)	425
Bottom Bracket Drop (mm)	21
Reach (mm)	403
Stack (mm)	565
Standover Height (mm)	771
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

	xs
Top Tube Horizontal (mm)	541
Head Tube Angle (deg)	65.5
Head Tube Length (mm)	90
Seat Tube Angle (deg)	76.5
Seat Tube Length (mm)	355
Rear Centre (mm)	425
Bottom Bracket Drop (mm)	19
Reach (mm)	405
Stack (mm)	566
Standover Height (mm)	772
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	542
Head Tube Angle (deg)	64.7
Head Tube Length (mm)	90
Seat Tube Angle (deg)	75.7
Seat Tube Length (mm)	355
Rear Centre (mm)	426
Bottom Bracket Drop (mm)	28
Reach (mm)	397
Stack (mm)	561
Standover Height (mm)	769
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	542
Head Tube Angle (deg)	64.9
Head Tube Length (mm)	90
Seat Tube Angle (deg)	75.9
Seat Tube Length (mm)	355
Rear Centre (mm)	426
Bottom Bracket Drop (mm)	26
Reach (mm)	400
Stack (mm)	563
Standover Height (mm)	770
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	541
Head Tube Angle (deg)	65.3
Head Tube Length (mm)	90
Seat Tube Angle (deg)	76.1
Seat Tube Length (mm)	355
Rear Centre (mm)	425
Bottom Bracket Drop (mm)	21
Reach (mm)	403
Stack (mm)	565
Standover Height (mm)	771
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

View from drive side

Top Tube Horizontal (mm)	541
Head Tube Angle (deg)	65.5
Head Tube Length (mm)	90
Seat Tube Angle (deg)	76.5
Seat Tube Length (mm)	355
Rear Centre (mm)	425
Bottom Bracket Drop (mm)	19
Reach (mm)	405
Stack (mm)	566
Standover Height (mm)	772
Wheelbase (mm)	1127

Standover height is measured 200 mm in front of the bottom bracket.

Sizing chart

These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size. Rocky Mountain always recommends test riding and professional bike fitting at an authorized dealer.

Frame Size

27.5”: 142.5 - 157.5 cm / 4’8” - 5’2”

29”: Not available for this frame size

27.5”: Not available for this frame size

29”: 157.5 - 170 cm / 5’2” - 5’7”

27.5”: Not available for this frame size

29”: 167.5 - 177.5 cm / 5’6” - 5’10”

27.5”: Not available for this frame size

29”: 175 - 188 cm / 5’9” - 6’2”

27.5”: Not available for this frame size

29”: 185.5 - 198 cm / 6’1” - 6’6”

Owners resources

Features and technologies

RIDE-4™ adjustment system

The RIDE-4 adjustment system allows riders to quickly fine-tune their geometry with a single Allen key. Four configurations are possible thanks to one rotating chip.

Size Specific Tune

Size Specific Tune ensures that riders of all sizes get the right balance of small-bump compliance, mid-stroke support, and end-stroke progressiveness. Our design team does custom shock tunes based on real world field testing, and adjusts each tune for specific frame sizes.

SMOOTHWALL™ Carbon

Smoothwall carbon uses one of the world’s most sophisticated carbon processes to deliver industry leading stiffness-to-weight, ride quality, and durability.
