Instinct Powerplay Alloy 50
Overview
Intended use: Trail
Rear travel: 140
Description
The Instinct Powerplay is built for exploration. Versatile geometry, dialed kinematics, and powered by our Dyname 4.0 drive system, you’ll be riding bigger days than ever before.
Instinct Powerplay Alloy 50
Sale price$6,999.00
Regular price (/)
Specifications
Geometry
Wheel size
RIDE-9/4 POSITION
View from drive side
| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 585 | 610 | 638 | 671 |
| Head Tube Angle (deg) | 64.2 | 64.2 | 64.2 | 64.2 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.2 | 76.2 | 76.2 | 76.2 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 439 | 439 | 439 | 439 |
| Bottom Bracket Drop (mm) | 42 | 42 | 42 | 42 |
| Reach (mm) | 432 | 457 | 482 | 512 |
| Stack (mm) | 624 | 624 | 632 | 646 |
| Standover Height (mm) | 819 | 818 | 817 | 818 |
| Wheelbase (mm) | 1201 | 1226 | 1256 | 1292 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 585 | 610 | 637 | 670 |
| Head Tube Angle (deg) | 64.4 | 64.4 | 64.4 | 64.4 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.4 | 76.4 | 76.4 | 76.4 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 438 | 438 | 438 | 438 |
| Bottom Bracket Drop (mm) | 39 | 39 | 39 | 39 |
| Reach (mm) | 435 | 460 | 485 | 515 |
| Stack (mm) | 622 | 622 | 630 | 644 |
| Standover Height (mm) | 820 | 820 | 820 | 820 |
| Wheelbase (mm) | 1201 | 1226 | 1255 | 1292 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 584 | 609 | 636 | 670 |
| Head Tube Angle (deg) | 64.7 | 64.7 | 64.7 | 64.7 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.7 | 76.7 | 76.7 | 76.7 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 437 | 437 | 437 | 437 |
| Bottom Bracket Drop (mm) | 36 | 36 | 36 | 36 |
| Reach (mm) | 438 | 463 | 488 | 518 |
| Stack (mm) | 620 | 620 | 628 | 642 |
| Standover Height (mm) | 822 | 821 | 821 | 821 |
| Wheelbase (mm) | 1200 | 1225 | 1254 | 1291 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 583 | 608 | 636 | 669 |
| Head Tube Angle (deg) | 64.95 | 64.95 | 64.95 | 64.95 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.95 | 76.95 | 76.95 | 76.95 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 436 | 436 | 436 | 436 |
| Bottom Bracket Drop (mm) | 32 | 32 | 32 | 32 |
| Reach (mm) | 441 | 466 | 491 | 520 |
| Stack (mm) | 618 | 618 | 626 | 639 |
| Standover Height (mm) | 823 | 823 | 823 | 823 |
| Wheelbase (mm) | 1199 | 1224 | 1253 | 1290 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| Top Tube Horizontal (mm) | 585 | 610 | 638 | 671 |
| Head Tube Angle (deg) | 64.2 | 64.2 | 64.2 | 64.2 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.2 | 76.2 | 76.2 | 76.2 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 439 | 439 | 439 | 439 |
| Bottom Bracket Drop (mm) | 42 | 42 | 42 | 42 |
| Reach (mm) | 432 | 457 | 482 | 512 |
| Stack (mm) | 624 | 624 | 632 | 646 |
| Standover Height (mm) | 819 | 818 | 817 | 818 |
| Wheelbase (mm) | 1201 | 1226 | 1256 | 1292 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| Top Tube Horizontal (mm) | 585 | 610 | 637 | 670 |
| Head Tube Angle (deg) | 64.4 | 64.4 | 64.4 | 64.4 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.4 | 76.4 | 76.4 | 76.4 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 438 | 438 | 438 | 438 |
| Bottom Bracket Drop (mm) | 39 | 39 | 39 | 39 |
| Reach (mm) | 435 | 460 | 485 | 515 |
| Stack (mm) | 622 | 622 | 630 | 644 |
| Standover Height (mm) | 820 | 820 | 820 | 820 |
| Wheelbase (mm) | 1201 | 1226 | 1255 | 1292 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| Top Tube Horizontal (mm) | 584 | 609 | 636 | 670 |
| Head Tube Angle (deg) | 64.7 | 64.7 | 64.7 | 64.7 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.7 | 76.7 | 76.7 | 76.7 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 437 | 437 | 437 | 437 |
| Bottom Bracket Drop (mm) | 36 | 36 | 36 | 36 |
| Reach (mm) | 438 | 463 | 488 | 518 |
| Stack (mm) | 620 | 620 | 628 | 642 |
| Standover Height (mm) | 822 | 821 | 821 | 821 |
| Wheelbase (mm) | 1200 | 1225 | 1254 | 1291 |
Standover height is measured 200 mm in front of the bottom bracket.
View from drive side
| Top Tube Horizontal (mm) | 583 | 608 | 636 | 669 |
| Head Tube Angle (deg) | 64.95 | 64.95 | 64.95 | 64.95 |
| Head Tube Length (mm) | 100 | 100 | 110 | 125 |
| Seat Tube Angle (deg) | 76.95 | 76.95 | 76.95 | 76.95 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 436 | 436 | 436 | 436 |
| Bottom Bracket Drop (mm) | 32 | 32 | 32 | 32 |
| Reach (mm) | 441 | 466 | 491 | 520 |
| Stack (mm) | 618 | 618 | 626 | 639 |
| Standover Height (mm) | 823 | 823 | 823 | 823 |
| Wheelbase (mm) | 1199 | 1224 | 1253 | 1290 |
Standover height is measured 200 mm in front of the bottom bracket.
