Solo Alloy 30

Name: Solo Alloy 30
Brand: Rocky Mountain
SKU: B0373XS1
Price: 2999.0 AUD
Availability: OutOfStock

$2,999.00

Overview

Intended use: Gravel

Rear travel:

Description

Designed to make every ride an adventure, the Solo is the perfect tool to escape, log some miles, and make multi-day rides a blast.

Wheel Size:

700

Color:

Smokin' in the Boys Room / Bad to the Bone

Variant

Register your Solo Alloy 30

Find a dealer

5-year warranty, transferable to second owners

We believe in our products, that's why we offer 5-year warranty on our frames, extended to second owners. Learn more

We're here for you

Got questions about our bikes? Our support team and dealers network are here for you.

Specifications

Geometry

Wheel size

	xs	sm	md	lg	xl
Top Tube Horizontal (mm)	520	540	560	580	605
Head Tube Angle (deg)	70	70.5	71	71.5	71.5
Head Tube Length (mm)	100	130	150	185	210
Seat Tube Angle (deg)	75	74.5	74	73.5	73
Seat Tube Length (mm)	414	452	490	528	566
Rear Centre (mm)	425	425	425	425	425
Bottom Bracket Drop (mm)	78	77	75	75	75
Reach (mm)	375.8	382.66	391.9	395.9	407.7
Stack (mm)	538.2	567.4	586.2	621.4	645.1
Standover Height (mm)	754	787	814	850	877
Wheelbase (mm)	1021	1034	1045	1056	1076

Standover height is measured 200 mm in front of the bottom bracket.

Top Tube Horizontal (mm)	520	540	560	580	605
Head Tube Angle (deg)	70	70.5	71	71.5	71.5
Head Tube Length (mm)	100	130	150	185	210
Seat Tube Angle (deg)	75	74.5	74	73.5	73
Seat Tube Length (mm)	414	452	490	528	566
Rear Centre (mm)	425	425	425	425	425
Bottom Bracket Drop (mm)	78	77	75	75	75
Reach (mm)	375.8	382.66	391.9	395.9	407.7
Stack (mm)	538.2	567.4	586.2	621.4	645.1
Standover Height (mm)	754	787	814	850	877
Wheelbase (mm)	1021	1034	1045	1056	1076

Standover height is measured 200 mm in front of the bottom bracket.

Sizing chart

These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size. Rocky Mountain always recommends test riding and professional bike fitting at an authorized dealer.

Frame Size

152.5 - 165 cm / 5’0” - 5’5”

157.5 - 170 cm / 5’2” - 5’7”

167.5 - 177.5 cm / 5’6” - 5’10”

175 - 188 cm / 5’9” - 6’2”

185.5 - 198 cm / 6’1” - 6’6”

Owners resources

Features and technologies

FORM™ Alloy

FORM™ tubesets utilize premium materials to meet our strict requirements. Each FORM™ tube that we create is engineered for its specific purpose within the frame, ensuring optimized strength, weight, and ride quality.
