| sm | md | lg | xl | |
|---|---|---|---|---|
| Top Tube Horizontal (mm) | 600.25 | 627.79 | 655.33 | 680.33 |
| Head Tube Angle (deg) | 66.5 | 66.5 | 66.5 | 66.5 |
| Head Tube Length (mm) | 100 | 110 | 120 | 120 |
| Seat Tube Angle (deg) | 74.5 | 74.5 | 74.5 | 74.5 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 445 | 450 | 455 | 460 |
| Bottom Bracket Drop (mm) | 60 | 60 | 60 | 60 |
| Reach (mm) | 425 | 450 | 475 | 500 |
| Stack (mm) | 631.91 | 641.08 | 650.25 | 650.25 |
| Standover Height (mm) | 796 | 795 | 791 | 786 |
| Wheelbase (mm) | 1165 | 1199 | 1233 | 1263 |
Standover height is measured 200 mm in front of the bottom bracket.
| Top Tube Horizontal (mm) | 600.25 | 627.79 | 655.33 | 680.33 |
| Head Tube Angle (deg) | 66.5 | 66.5 | 66.5 | 66.5 |
| Head Tube Length (mm) | 100 | 110 | 120 | 120 |
| Seat Tube Angle (deg) | 74.5 | 74.5 | 74.5 | 74.5 |
| Seat Tube Length (mm) | 380 | 420 | 445 | 480 |
| Rear Centre (mm) | 445 | 450 | 455 | 460 |
| Bottom Bracket Drop (mm) | 60 | 60 | 60 | 60 |
| Reach (mm) | 425 | 450 | 475 | 500 |
| Stack (mm) | 631.91 | 641.08 | 650.25 | 650.25 |
| Standover Height (mm) | 796 | 795 | 791 | 786 |
| Wheelbase (mm) | 1165 | 1199 | 1233 | 1263 |
Standover height is measured 200 mm in front of the bottom bracket.
| xs | |
|---|---|
| Top Tube Horizontal (mm) | 559 |
| Head Tube Angle (deg) | 65.5 |
| Head Tube Length (mm) | 110 |
| Seat Tube Angle (deg) | 74.5 |
| Seat Tube Length (mm) | 345 |
| Rear Centre (mm) | 440 |
| Bottom Bracket Drop (mm) | 50 |
| Reach (mm) | 395 |
| Stack (mm) | 592 |
| Standover Height (mm) | 777 |
| Wheelbase (mm) | 1123 |
Standover height is measured 200 mm in front of the bottom bracket.
| Top Tube Horizontal (mm) | 559 |
| Head Tube Angle (deg) | 65.5 |
| Head Tube Length (mm) | 110 |
| Seat Tube Angle (deg) | 74.5 |
| Seat Tube Length (mm) | 345 |
| Rear Centre (mm) | 440 |
| Bottom Bracket Drop (mm) | 50 |
| Reach (mm) | 395 |
| Stack (mm) | 592 |
| Standover Height (mm) | 777 |
| Wheelbase (mm) | 1123 |
Standover height is measured 200 mm in front of the bottom bracket.
These figures are a rough guide only. Rider proportions, riding style, and personal preferences all factor in choosing the correct bike size. Rocky Mountain always recommends test riding and professional bike fitting at an authorized dealer.
Find more information about critical dimensions and key standards in our knowledge base.
The Fusion Powerplay is a wonderful bike, well made and thought out. It meets my needs perfectly. Handles great out on the trail and well as in the city. A bit heavy, so not quite as nimble as a non-powered bike but to be expected. The motor controls are simple to use and convenient. Components are all quality.
